Single-sided PCBs are the oldest type, yet they are still commonly used in industries such as households, white goods, and lighting.
| Feature | Odak PCB's technical specifications |
|---|---|
| Number of layers | 1 layer |
| Materials | CEM 1, FR4, CEM 3, IMS, |
| Copper thicknesses | 35 μm - 105 μm |
| Pcb thickness | 0.4 mm to 2.4 mm |
| Minimum line width | 200 μm |
| Minimum copper to copper | 200 μm |
| Maximum panel size | 500 mm x 700 mm |
| Surface finish | Lead-Free HASL, OSP, ENIG |
| Minimum hole size | 0.5 mm |
When starting a new printed circuit board design, you may spend most of your time focusing on the circuit design and component selection. However, the design might translate poorly from the digital domain to physical reality without a guideline provided by your PCB manufacturer. We have prepared a guideline for you to make the right decisions at the design stage from the very beginning.
